610钢管平头倒棱机

一.概述:introduction

钢管平头倒棱机用于对钢管两端按要求进行焊接坡口的倒棱和平头工作。

 该设备为两个倒棱机头布置在同一轴线上，每个倒棱机头上装有床头箱、刀盘、夹紧装置等，刀盘上装有倒棱刀具和平头刀具，倒棱刀为径向浮动，工作时钢管不动，夹紧装置将钢管夹紧，刀盘旋转，倒棱刀浮动旋转，从而进行钢管的仿型刀棱加工。

Themachine is used to face the ends and bevel the pipes according to the workrequirment. It has two bevelling heads which are at the same axle line, andeach head is fixed with headstock, cutter and clamping device etc, and cutterhave bevelling cutter and end facing cutter, the bevelling cutter is floatingat radial, During working, the pipe is fixed by clamping deive, rotate thecutter, the bevelling cutter is rotating and floating, in order to do themachining work of copy-bevelling cutter.

二.技术性能参数Technical parameter

1. 原材料 material

2.机组主要性能 main performance

4.动力参数 power data

三.工艺流程technical process

人工将钢管推进→受拨管器升降→钢管放入夹具→左右夹紧臂分别闭合→锁紧缸锁紧→机头旋转→机头进给→两头同时切削，切削完毕→钢管送出→设备复位，准备下次循环。

Pushingthe pipe by manual→lift the tube pulling machine up & down→ entry toclamping device → close the right and left clmaping arm→ lock by lockingcylinder→ the unit head rotates→the unit head feeds→cutting the two sides atone time, finishing the cutting → send out the pipe→ reset the machine and nextrecycle.

四．设备明细、报价及说明machine list and price

1.设备组成：machine list
